Serie 352
HTT, or OEM job
MPP +
Para cortar los orificios en madera áspera, placa llana, tablero recubierto laminado, madera contrachapada, laminado de base de papel, PVC, fibra de vidrio, plástico reforzado, hormigón de gas, piedra ytong, tablero de yeso, azulejos de arcilla y ladrillo de calibre hueco, baldosas hasta rayas. 6.
352
14mm Uptown 210mm
1 / 2-20UNF, 5/8-18UNF
Trabajos de albañilería, Trabajo en madera
| Cantidad: | |
|---|---|
Tabla de tamaño:
| Número de artículo | Diámetro (mm) | Diámetro (pulgada) | T.c.t. Cantidad. | Conexión roscada |
| 352.10140160 | 14 | 9/16 \" | 1 | 1 / 2-20UNF |
| 352.10160160 | 16 | 5/8 \" | 1 | 1 / 2-20UNF |
| 352.10170160 | 17 | 11/16 \" | 1 | 1 / 2-20UNF |
| 352.10180160 | 18 | 23/32 \" | 1 | 1 / 2-20UNF |
| 352.10190160 | 19 | 3/4 \" | 1 | 1 / 2-20UNF |
| 352.10200160 | 20 | 25/32 \" | 1 | 1 / 2-20UNF |
| 352.10210160 | 21 | 13/18 \" | 1 | 1 / 2-20UNF |
| 352.10220160 | 22 | 7/8 \" | 1 | 1 / 2-20UNF |
| 352.10240160 | 24 | 15/16 \" | 1 | 1 / 2-20UNF |
| 352.10250160 | 25 | 1 \" | 1 | 1 / 2-20UNF |
| 352.10270160 | 27 | 1-1 / 16 \" | 1 | 1 / 2-20UNF |
| 352.10280160 | 28 | 1-1 / 8 \" | 1 | 1 / 2-20UNF |
| 352.10290160 | 29 | 1-1 / 8 \" | 1 | 1 / 2-20UNF |
| 352.10300160 | 30 | 1-3 / 16 \" | 1 | 1 / 2-20UNF |
| 352.10320160 | 32 | 1-1 / 4 \" | 1 | 5 / 8-18unf |
| 352.10330160 | 33 | 1-5 / 16 \" | 1 | 5 / 8-18unf |
| 352.10350160 | 35 | 1-3 / 8 \" | 2 | 5 / 8-18unf |
| 352.10360160 | 36 | 1-27 / 64 \" | 2 | 5 / 8-18unf |
| 352.10370160 | 37 | 1-7 / 16 \" | 2 | 5 / 8-18unf |
| 352.10380160 | 38 | 1-1 / 2 \" | 2 | 5 / 8-18unf |
| 352.10400160 | 40 | 1-9 / 16 \" | 2 | 5 / 8-18unf |
| 352.10410160 | 41 | 1-5 / 8 \" | 2 | 5 / 8-18unf |
| 352.10430160 | 43 | 1-11 / 16 \" | 2 | 5 / 8-18unf |
| 352.10440160 | 44 | 1-3 / 4 \" | 2 | 5 / 8-18unf |
| 352.10450160 | 45 | 1-25 / 32 \" | 2 | 5 / 8-18unf |
| 352.10460160 | 46 | 1-13 / 16 \" | 2 | 5 / 8-18unf |
| 352.10470160 | 47 | 1-27 / 32 \" | 2 | 5 / 8-18unf |
| 352.10480160 | 48 | 1-7 / 8 \" | 2 | 5 / 8-18unf |
| 352.10490160 | 49 | 1-15 / 16 \" | 2 | 5 / 8-18unf |
| 352.10500160 | 50 | 1-31 / 32 \" | 2 | 5 / 8-18unf |
| 352.10510160 | 51 | 2 \" | 3 | 5 / 8-18unf |
| 352.10520160 | 52 | 2-1 / 16 \" | 3 | 5 / 8-18unf |
| 352.10540160 | 54 | 2-1 / 8 \" | 3 | 5 / 8-18unf |
| 352.10560160 | 56 | 2-3 / 16 \" | 3 | 5 / 8-18unf |
| 352.10570160 | 57 | 2-1 / 4 \" | 3 | 5 / 8-18unf |
| 352.10590160 | 59 | 2-5 / 16 \" | 3 | 5 / 8-18unf |
| 352.10600160 | 60 | 2-3 / 8 \" | 3 | 5 / 8-18unf |
| 352.10610160 | 61 | 2-13 / 32 \" | 3 | 5 / 8-18unf |
| 352.10620160 | 62 | 2-7 / 16 \" | 3 | 5 / 8-18unf |
| 352.10630160 | 63 | 2-31 / 64 \" | 3 | 5 / 8-18unf |
| 352.10640160 | 64 | 2-1 / 2 \" | 3 | 5 / 8-18unf |
| 352.10650160 | 65 | 2-9 / 16 \" | 3 | 5 / 8-18unf |
| 352.10660160 | 66 | 2-19 / 32 \" | 3 | 5 / 8-18unf |
| 352.10670160 | 67 | 2-5 / 8 \" | 3 | 5 / 8-18unf |
| 352.10680160 | 68 | 2-11 / 16 \" | 3 | 5 / 8-18unf |
| 352.10700160 | 70 | 2-3 / 4 \" | 3 | 5 / 8-18unf |
| 352.10710160 | 71 | 2-25 / 32 \" | 3 | 5 / 8-18unf |
| 352.10730160 | 73 | 2-7 / 8 \" | 3 | 5 / 8-18unf |
| 352.10760160 | 76 | 3 \" | 4 | 5 / 8-18unf |
| 352.10770160 | 77 | 3-1 / 32 \" | 4 | 5 / 8-18unf |
| 352.10790160 | 79 | 3-1 / 8 \" | 4 | 5 / 8-18unf |
| 352.10800160 | 80 | 3-5 / 32 \" | 4 | 5 / 8-18unf |
| 352.10820160 | 82 | 3-15 / 64 \" | 4 | 5 / 8-18unf |
| 352.10830160 | 83 | 3-1 / 4 \" | 4 | 5 / 8-18unf |
| 352.10860160 | 86 | 3-3 / 8 \" | 4 | 5 / 8-18unf |
| 352.10890160 | 89 | 3-1 / 2 \" | 4 | 5 / 8-18unf |
| 352.10900160 | 90 | 3-9 / 16 \" | 4 | 5 / 8-18unf |
| 352.10920160 | 92 | 3-5 / 8 \" | 4 | 5 / 8-18unf |
| 352.10950160 | 95 | 3-3 / 4 \" | 4 | 5 / 8-18unf |
| 352.10980160 | 98 | 3-7 / 8 \" | 4 | 5 / 8-18unf |
| 352.11000160 | 100 | 3-15 / 16 \" | 4 | 5 / 8-18unf |
| 352.11020160 | 102 | 4 \" | 5 | 5 / 8-18unf |
| 352.11050160 | 105 | 4-1 / 8 \" | 5 | 5 / 8-18unf |
| 352.11080160 | 108 | 4-1 / 4 \" | 5 | 5 / 8-18unf |
| 352.11110160 | 111 | 4-3 / 8 \" | 5 | 5 / 8-18unf |
| 352.11140160 | 114 | 4-1 / 2 \" | 5 | 5 / 8-18unf |
| 352.11180160 | 118 | 4-21 / 32 \" | 6 | 5 / 8-18unf |
| 352.11210160 | 121 | 4-3 / 4 \" | 6 | 5 / 8-18unf |
| 352.11250160 | 125 | 4-15 / 16 \" | 6 | 5 / 8-18unf |
| 352.11270160 | 127 | 5 \" | 6 | 5 / 8-18unf |
| 352.11330160 | 133 | 5-1 / 4 \" | 6 | 5 / 8-18unf |
| 352.11380160 | 138 | 5-7 / 16 \" | 6 | 5 / 8-18unf |
| 352.11400160 | 140 | 5-1 / 2 \" | 6 | 5 / 8-18unf |
| 352.11460160 | 146 | 5-3 / 4 \" | 6 | 5 / 8-18unf |
| 352.11520160 | 152 | 6 \" | 6 | 5 / 8-18unf |
| 352.11590160 | 159 | 6-17 / 64 \" | 6 | 5 / 8-18unf |
| 352.11600160 | 160 | 6-19 / 64 \" | 6 | 5 / 8-18unf |
| 352.11650160 | 165 | 6-1 / 2 \" | 6 | 5 / 8-18unf |
| 352.11680160 | 168 | 6-5 / 8 \" | 6 | 5 / 8-18unf |
| 352.11770160 | 177 | 6-31 / 32 \" | 6 | 5 / 8-18unf |
| 352.11850160 | 185 | 7-9 / 32 \" | 6 | 5 / 8-18unf |
| 352.12000160 | 200 | 7-7 / 8 \" | 6 | 5 / 8-18unf |
| 352.12100160 | 210 | 8-17 / 64 \" | 6 | 5 / 8-18unf |
| Número de artículo | Descripciones de accesorios |
| 352.10010001 | Arbor con taladro piloto HSS 3/8 \"Hex Shank, para cortador de agujeros 14-30mm |
| 352.10020001 | Arbor con taladro piloto HSS 7/16 \"Hex Shank, para cortador de agujeros 32-210mm |
| 352.10070001 | Arbor de liberación rápida con taladro piloto HSS, 7/16 \"Hex Shank para cortador de agujeros 32-210mm |
| 352.10080001 | Taladro piloto hss 6.35 x 95mm ol |
| 352.10100001 | TCT Piloto Taladro 8 x 95mm OL |
